BROTHER Z-8560A-431 UBT ZIG ZAG HEAD ONLY FULLY AUTO
Description / BROTHER Z-8560A-431 UBT ZIG ZAG HEAD ONLY FULLY AUTO
Brother Z-8560A-431
- Electronic Direct Drive zigzag lockstitcher with thread trimmer, upper thread feding device, backtack / condense device, and thread wiper.
The energy-saving direct drive and clean dry head technology have been adopted. Great capability for various pattern sewing, widening sewing possibilities.
Clean Sewing
The Z-8550A and Z-8560A are equipped with a sealed oil tank, supplying constant clean oil only to the rotary hook. Having no oil around the needle bar and thread take-up mechanism, there is no concern of oil staining.The direct drive system, having no shaving of the belt, can keep valued products clean.
Plain zigzag, 3-step zigzag, scallop patterns and T-stitches are provided
The basic 8 types, 14 sewing patterns are built-in. Users do not need to have multiple cams for each sewing pattern, which allows excellent cost performance.
Custom sewing patterns adding value to the product
Users can store their original sewing patterns in the machine additionally. Custom patterns can be used in a wide variety of applications, such as decorative stitching of ladies wear, knitted articles, neckerchiefs, towel handkerchiefs, foundation garments and swimming wear. Data handling is easily made with CF cards, adopted as storage media. (Up to 99 patterns with a total of 49,500 stitches, 500 stitches or less per pattern. Sewing patterns can be created at the operation panel or by using the sewing data programming software PS-300B (Option).)
Enhanced Sewing Quality
Simple Setting for condensed stitches
Setting for condensed stitch, making stitches (feed amount) finer at backtaking, can easily be made with the adjustment dial.
Minute-adjustable pressing level
Pressing level of the presser foot can minutely be lifted in accordance with materials. Its is suitable for sewing of stretch fabric materials and riased fabrics, preventing stitch slippage and damage to the fabrics.
Trouble-feed hook shaft offset mechanism
This mechanism prevents skipped stitches and thread breakages which tend to occur at the needle's right zigzag position. It also makes needle and rotary hook timing adjustment easier and improves the maintenance operation. Damage of the rotary hook tip by the needle guard can be prevented as well.
Soft, quality sewing finishes
Improvements have been made to enable soft sewing finishes with low thread tension, such as of needle and rotary hook timing, shapes of the rotary hook and the thread take-up, and the thread path.
Thread trimming error can be prevented
Grooved cam methos, which eliminates thread trimming error, has been adopted. In addition, the knife mechanism is unitised in one unit, allowing for simple maintenance.
Thread cast-off at sewing start can be prevented
The upper thread feeding device supplied just teh necessary length of upper thread at the sewing start.
Technical Specification
| Model | Brother Z-8560A-431 |
|---|---|
| Thread Trimmer | Yes |
| Backtack / Condensed Stitch Device | Yes |
| Upper Thread Feeding Device | Yes |
| thread wiper | Yes |
| Direct drive | Yes |
| Max. zigzag width | 10.0mm |
| Application | Light materials Medium materials |
| Presser foot height | Manual: 6.0mm Knee: 10.0mm |
| Needle bar stroke | 33mm |
| Max. sewing speed | 5,000sti/min |
| Max. feed amount | 5.0mm |
| Sewing pattern | 8 types, 14 patterns built-in (Custom patterns can be added up to 99 patterns with a total of 49,500 stitches, 500 stitches or less per pattern.) |
| Thread take-up | Rotary |
| Height of feed dog | 1.0mm |
| Presser foot pressure | 10-60N |
| Needle | Schmetz 134SUK Nm70/10 |
| Weight | Machine head: 44.4kg Control box: 14-15kg |
| Arm pocket size | Arm pocket width: 300.0mm Arm pocket height: 121.5mm |
| Arm pocket size | Arm pocket width : 300.0mm Arm pocket height : 121.5mm |
| Arm bed size | 517.5x178.0mm |
| Motor | AC servo motor (4-pole,450W) |
| Power | Single-phase, 3-phase: 200V-230V Max. electric power consumption: 400VA |
| Control circuit | Microprocessor |
More Information
| Part No | BROZ8560A431 |
|---|---|
| Weight (KG) | 0.100000 |
| Manufacturer | Brother |
