BROTHER Z-8550B-031 ZIG ZAG D/DRIVE WITHOUT TRIMMER

Part No BROZ8550B031
Brother Z-8550B-031 Nexio - Electronic Direct Drive Zigzag Lock Stitcher. Equipped with the colour LCD touch panel, it becomes easy to set various sewing patterns with intuitive operation of the display. The servo motor control greatlt improves the stitch patternaccuracy contributing to the improvement of sewing quality.
Pricing and Availability on Request
Contact Us for Quote

Description / BROTHER Z-8550B-031 ZIG ZAG D/DRIVE WITHOUT TRIMMER

Brother Z-8550B-031 Nexio
- Electronic Direct Drive Zigzag Lock Stitcher.

Equipped with the colour LCD touch panel, it becomes easy to set various sewing patterns with intuitive operation of the display. The servo motor control greatlt improves the stitch patternaccuracy contributing to the improvement of sewing quality.

User-Inuitive Color LCS display Touch Panel

The colour LCD display touch panel displays items with illustration icons, offering easy user-intuitive operation.

There are two types of operator panel displays. Both the detailed home screen and quick home screen are easy to use without concern for panel operation.

Displays the pattern liost on the panel screen so you can select more easily.

Productivity improvement with IoT capabilities

This model is IoT applicable. The visualisation by connectingsewing machine and computer technology enables the customer to analyse, manage process and speed up productivity improvement and maintenance work.

High sewing quality achieved by electronic control

The pulse motr control with servo control is adopted for the zigzag mechanism. The needle move perpendicular to the material so that needle deflection or position slippage does not occur even at high speed.

Clean sewing with no concern of oil staining

Equipped the sealed oil tank, supplying oil only to the rotary hook. Having no oil around the needle bar and thread take-up mechanism reduces concern for oil staning.

USB port on operation panel

The display panel is equipped with a USB port for sewing patterns and various environmental settings can be copied and shared easily with other sewing machines of the same. This also permits software upgrades to be performed using USB media.

Custom sewing patterns

You can add and save your own unique stitch patterns using the operation panel or PS-300B Software. You can easily copy data and upload to other sewing machines using the USB media. You canalso saved patterns edited on the control panel so it is easy to manage data.

Plain zigzag, 3-step zigzag, scallop patterns and T-stitches are already provided


Technical Specification

Model Brother Z-8550B-031
Direct drive Yes
Thread Trimmer No
Backtack / condensed stitch device No
Upper thread Feeding Device No
Max. zigzag width 10.0mm*1
Application Light materials
Medium materials
Presser foot height Manual : 6.0mm
Knee : 10.0mm
Needle bar stroke 33mm
Max. sewing speed 5,000sti/min*2
Max. feed amount 4.0mm*3
Sewing pattern 8 types, 14 patterns built-in*3
Height of feed dog 1.0mm
Presser foot pressure 10-35N
Needle Schmetz 134SUKNm70/10
Weight Machine head : 49kg
Control box: 8kg
Arm pocket size Arm pocket width : 300.0mm
Arm pocket height : 121.5mm
Arm pocket size Arm pocket width : 300.0mm
Arm pocket height : 121.5mm
Arm bed size 517.5x178.0mm
Motor AC servo motor (450W)
Power Single-phase, 3-phase: 200V -230V
Max. electric power consumption: 400VA

Product Attachments

More Information

Part No BROZ8550B031
Weight (KG) 0.100000
Manufacturer Brother
