YAMATO AZ 7120SDR Y5DF-8 OVERLOCK HEAD ONLY

Part No AZ7120SDRY5DF8
Yamato AZ-7120SDR-Y5DF-8 - 2-Needle, 4-Thread “Speed & Dry” Overlock Machine – Wide Seam Width. The Yamato AZ-7120SDR-Y5DF-8 is a high-performance overlock machine designed for wide seam widths, combining speed, durability, and a stain-free dry finish. Part of the AZ7000SDR-8 and AZ7500SDR-8 series, it features Yamato’s proprietary Speed + Dry (SD) Technology, delivering exceptional productivity and garment quality.
Pricing and Availability on Request
Have a Question? Let us advise you

If you've got a question about our products, call us on +44 (0)161 763 6969 to speak to our team or get in touch here.

Delivery Information

We offer free delivery on every online order over £200 (Net, UK Mainland only — restrictions may apply).

For international orders, the minimum order value we're able to process is £20.00 (Net).

International delivery methods include Economy and Express, with rates calculated at checkout. Please note: Economy delivery to EU27 countries is currently suspended.

Read more about our delivery options on our Freight Charges Explained page.

Description / YAMATO AZ 7120SDR Y5DF-8 OVERLOCK HEAD ONLY

Yamato AZ-7120SDR-Y5DF-8
- 2-Needle, 4-Thread “Speed & Dry” Overlock Machine – Wide Seam Width.

The Yamato AZ-7120SDR-Y5DF-8 is a high-performance overlock machine designed for wide seam widths, combining speed, durability, and a stain-free dry finish. Part of the AZ7000SDR-8 and AZ7500SDR-8 series, it features Yamato’s proprietary Speed + Dry (SD) Technology, delivering exceptional productivity and garment quality.

This 3-in-1 overlock and safety stitch machine supports high-speed operation while preventing oil stains, ensuring clean finishes and long machine life. Built for demanding production environments, it offers reliable performance, reduced maintenance, and consistent stitch quality.

Key Features:

  • High-speed operation for increased productivity
  • Stain-free dry finish for superior garment quality
  • Wide seam width capability
  • Overlock and safety stitch functions in one machine
  • Enhanced durability and long service life

Technical Specification

Model Yamato AZ-7120SDR-Y5DF-8
Needle System DCx27
Number of Needles 2
Number of Threads 4
Needle distance (mm) 2.4
Over-edge seam width (mm) 5, 6, 7, 8
Stitch length (mm) 1.0 - 4.0
Feed regulation Push button
Differential ratio 1:0.6 - 1:2.3
Differential feed regulation Lever with micro-adjuster
Presser foot lift (mm) 6.0
Needle stroke (mm) 23.7
Machine speed (sti/min) 7,000
Applications For Wide Seam Width

More Information

Part No AZ7120SDRY5DF8
Weight (KG) 32.000000
Manufacturer Yamato
