PEGASUS M952-52-2X4/D222 4 TH 2X4MM DIRECT DRIVE HEAD ONLY

Part No M952522X4D222
Pegasus M952-52-2x4 (/D222) - 4-Thread Direct Drive Head Overedging Machine – Light to Medium Weight Fabrics. The Pegasus M952-52-2x4 is a high-performance 4-thread overedging machine from the M900 Series, designed for light to medium-weight fabrics. Combining Pegasus’ advanced technology with cost-effective design, it delivers high-speed operation with minimal heat, noise, and vibration, increasing productivity while maintaining seam quality.
Pricing and Availability on Request

Description / PEGASUS M952-52-2X4/D222 4 TH 2X4MM DIRECT DRIVE HEAD ONLY

Pegasus M952-52-2x4 (/D222)
- 4-Thread Direct Drive Head Overedging Machine – Light to Medium Weight Fabrics.

The Pegasus M952-52-2x4 is a high-performance 4-thread overedging machine from the M900 Series, designed for light to medium-weight fabrics. Combining Pegasus’ advanced technology with cost-effective design, it delivers high-speed operation with minimal heat, noise, and vibration, increasing productivity while maintaining seam quality.

Enhanced Dirt and Dust Protection

The Pegasus M900 Series features advanced oil-blocking mechanisms, including a fully enclosed needle bar chamber with a force-drain function, protecting fabrics from oil stains. The upper looper mechanism incorporates additional functions to prevent dirt and dust from entering the machine, ensuring cleaner operation, reducing maintenance, and contributing to higher productivity.

Key Features:

  • Direct Drive Motor: Efficient, precise, and low-maintenance operation
  • High-Speed Performance: Smooth, consistent overedging for light-to-medium weight fabrics
  • Dirt & Dust Prevention: Fully enclosed needle bar chamber and force-drain oiling system protect fabrics from oil stains and machine contamination
  • Enhanced Looper Mechanism: Additional features minimize dust and dirt intrusion, ensuring reliable operation and longevity
  • Durable & Reliable: Designed and manufactured by Pegasus for long-term performance
  • Compliance: Meets EU standards

Technical Specification

Model Pegasus M952-52-2x4(/D222)
Stitch length adjustment Push-button
Differential feed ratio adjustment Lever
Lubrication Fully-automatic
Fabric Weight Light～Medium
Max. machine speed(sti/min) 7,000
No. of needles 2
No. of threads 4
Needle space(mm) 2
Overedge width 4
Accessories Needle plate with chaining land, With presser foot for attaching tape
Remarks Multi use for plain seam and attach tape

More Information

Part No M952522X4D222
Weight (KG) 32.000000
Manufacturer Pegasus
