Description / PC1062 SUPRENA MINI JET CUTTER
Suprena PC1062
- Air-Powered Cloth Cutting Machine.
The Suprena PC1062 is a handheld air-powered rotary cutter designed for precise, scissor-like fabric cutting. Equipped with a round knife blade and a carbide-tipped bottom blade, it easily cuts through a wide range of fabrics with minimal effort.
**3-month back-to-base warranty**
Its MINI JET pneumatic motor delivers powerful, high-speed performance and long, trouble-free operation.
Key Features:
- Recessed design for full visibility of the cutting line
- Powerful noise-dampening system
- Overload-resistant operation
- One-touch blade sharpener
- Stationary carbide counter blade
- Built-in felt pad oiler and lubrication system
- Lightweight design (0.9 kg / 2 lbs)
- Six types of high-speed steel knives available
- Ergonomic grip-style lever switch
- Two-in-one synchron system cutting base
Technical Specification
| Model | Suprena PC-1062 | |
|---|---|---|
| AIR MOTOR | ||
| Air Pressure Used | 4.5 kg/cm2 | |
| Max. Horse Power | 0.4 HP (300W) | |
| Max Torque | 0.032 kg-m | |
| Max. Speed with Load | 9,000 r.p.m (without load 20,000 r.p.m) | |
| Max. Air Consumption with Load | 3.5m3 / min (withoutload 0.45m3 / min) | |
| AIR INLET | ||
| Outside Diameter | 9.5mm (3/8") | |
| Inlet Screw Threading | 1/4 PT | |
| Compressor (Recommendable) | 1.0 HP compressor for 1 cutter | |
| CUTTER | ||
| Cutter | 3.0 HP compressor for 2 cutter | |
| Diameter of Knife | 50mm (2") | |
| Dimensions | (H) 80mm x (W) 50mm x (L) 235mm | |
| Standard Accessories | 2 x Knives (Round and 6-sided), 1 x Allen Screw Wretch, 1 x Grease, 1 x Oil | |
| Weight | (NW) 0.9 kg / (GW) 1.3 kg | |
More Information
| Part No | PC1062 |
|---|---|
| Weight (KG) | 1.850000 |
| Manufacturer | Suprena |
