JUKI PLC-2760RDV8-HMC 2N POST M/CH DECORATIVE STITCH

Part No JUKIPLC2760RDV8
JUKI PLC-2760RDV8-HMC - 2-needle, Semi-dry, Post-bed, Unison-feed, Lockstitch Machine with Vertical-axis 2.0 Fold-Capacity Hook, Decorative Stitch
Pricing and Availability on Request

Description / JUKI PLC-2760RDV8-HMC 2N POST M/CH DECORATIVE STITCH

JUKI PLC-2760RDV8-HMC
- 2-needle, Semi-dry, Post-bed, Unison-feed, Lockstitch Machine with Vertical-axis 2.0 Fold-Capacity Hook, Decorative Stitch

A dedicated control box and software with easy to navigate interface guarantees hassle-free selection from variety of different stitching patterns and adjusting of a stitch length. A turning needle bar system allows for abundant stitching pattern applications.

JUKI PLC-2760RDV8-HMC 2N POST M/CH DECORATIVE STITCH

Technical Specification

Model name Juki PLC 2760RDV8-HMC
Type 2-needle organized split needlebars type (V-belt type)
Max. Sewing speed 2,500sti/min*
Needle 135×17
Nm100~180
Standard Nm140
Thread TEX 50~167
Max. stitch length 12mm (forward / backward)
Stitch adjusting method 1 pitch dial
Thread take-up Link type
Automatic reverse feed function Lever type
Needle bar stroke 40mm
Hook Vertical-axis 2.0-fold capacity hook (latch type)
Lift of the presser foot By hand: 10mm
Auto: 18mm
Alternating vertical movement 1~9mm
Alternating vertical movement adjusting method Dial
DL device Provided as standard
Safety mechanism Provided as standard
Bobbin thread winder Built in the machine arm
Bottom-feed micro-adjustment mechanism Provided as standard
Lubrication Automatic (Tank system)
Distance from needle to machine arm 347mm
Post height 170mm
Knee-lifter Provided as standard
Auto-lifter Option
Weight of the machine head 80kg
Power requirement / Power consumption Single-phase 100~120V / 200~240V
3-phase 200~240V / 193VA (with automatic thread trimmer)
Air consumption 0.1dm³/min (ANR)

More Information

Part No JUKIPLC2760RDV8
Weight (KG) 32.000000
Manufacturer Juki
