JUKI MO-6904J-0F6-700 JEANS 3 THREAD TOP FEED OVERLOCK
Description / JUKI MO-6904J-0F6-700 JEANS 3 THREAD TOP FEED OVERLOCK
Juki MO-6904J-0F6-700
- Variable Top-feed, 1-Needle 3-Thread Overlock / Safety Stitch Machine for Extra Heavy-weight Materials
An advanced full-featured machine that is ideally suited to the sewing of extra heavy-weight materials
The MO-6900J Series comes with a newly-developed feed mechanism that moves the top and bottom feeds separately.
With its improved feeding capacity and stronger cloth-biting force, the feed mechanism prevents uneven material feed when sewing extra heavy-weight materials.
- The machine incorporates mechanisms that are both durable and reliable, such as the needle bar mechanism, utilyzing the upper and lower bushings, a cartridge type oil filter and cooling fan.
- The machine is equipped as standard with a micro-lifter that helps reduce operator fatigue. The micro-lifter is designed to achieve optimum balance, not only reducing noise and vibration but also ensuring comfortable operation.
- Needle thread heat remover and needle cooler prevent stitching troubles during times of high-speed sewing, thereby contributing to upgraded seam quality.
- The machine comes standard with various adjusting mechanisms, such as a micro-adjusting mechanism, all of which can be easily adjusted to enable the machine to perform sewing under the best-suited conditions for any kind of material.
Technical Specification
| Subclass Model | Juki MO-6904J-0F6-700 |
|---|---|
| Material | Extra Heavy-Weight |
| Number of Needles | 1 |
| Number of Threads | 3 |
| Needle Gauge | - |
| Overedging Width | 4.8mm |
| Number of Feed Dog Rows | 3 |
| Stitch Length | 5mm |
| Bottom differential-feed ratio | 1:0.7~1:1.75 |
| Longitudinal stroke of top feed dog | 2.71~7 |
| Presser lifting amount | 8mm |
| Needle system | Dox5 #21 |
| Max sewing speed | 6,000 sti/min* |
| Remarks | For runstitching extra heavy-weight materials such as denim |
More Information
| Part No | JUKIMO6904J0F6700 |
|---|---|
| Weight (KG) | 0.100000 |
| Manufacturer | Juki |
