JEUX AI-118 I-NNN HOT AIR SEALING MACHINE COMPLETE
Description / JEUX AI-118 I-NNN HOT AIR SEALING MACHINE COMPLETE
JEUX AI-118 I-NNN
- Hot Air Sealing Machine.
The JEUX AI-118 is an economical and user-friendly hot air sealing machine designed for a wide range of seam sealing applications. It features a functional color touchscreen and differential speed control for the top and bottom rollers, ensuring consistent sealing performance on difficult materials and curved seams.
Key Capabilities:
- Suitable for all bonding materials
- Compatible with tape widths from 4–30 mm
- Ideal for stretch fabrics
- Supports customized and upgradable software
- Multiple attachments available for different applications
Highlight Features:
- Ergonomic design with a large working area
- Differential speed top and bottom rollers for improved seam quality
- Patented interactive touchscreen interface, easy to learn and operate
- Multi-language support
- Digital air pressure display
- Automatic length calculation fit mode
- Standard digital tape tensioner for tape usage tracking
- Data locking function to prevent accidental parameter changes
- USB interface for data and system updates
- Built-in parameters for major tape brands and standard nozzle positioning fixture
- Simple, stable, and reliable electrical design
Technical Specification
| Model | JEUX AI-118 |
|---|---|
| Power Supply | AC 220V 50/60Hz, 1Φ |
| Power Consumption (W) | 3600 |
| Compressed Air (MPa) | > 0.4 |
| Maximum Sealing Speed (ft/min) | 80 |
| Maximum Temperature (ºC) | 800 |
| Nozzle Unit (MM) | 22 |
| Upper Roller Width (MM) | 25.4 |
| Lower Roller Width (MM) | 31 |
| Dimensions LxWxH (mm) | 1350 x 850 x 1560 |
| Net Weight (kg) | 130 |
| Optional Roller (MM) | 10-31 |
More Information
| Part No | JEUXAI1181NNN |
|---|---|
| Weight (KG) | 0.100000 |
| Manufacturer | Juki |
