BROTHER S-7180A-813II SINGLE NEEDLE MEDIUM WEIGHT DIRECT DRIVE AUTOMATIC LOCKSTICH MACHINE
Part No
BROS7180A813
- Technical Specification Brother S-7180A-813 - Single Needle Direct Drive Straight Lock Stitcher (Medium-Weight Materials) with Thread Trimmer, Electric Feeding System, and Presser Foot Lifter. With direct drive motor, electric presser foot lifter and stitch length, this machine offers beautiful sewing quality and high productivity.
Pricing and Availability on Request
Description / BROTHER S-7180A-813II SINGLE NEEDLE MEDIUM WEIGHT DIRECT DRIVE AUTOMATIC LOCKSTICH MACHINE
- Technical Specification
Brother S-7180A-813
- Single Needle Direct Drive Straight Lock Stitcher (Medium-Weight Materials) with Thread Trimmer, Electric Feeding System, and Presser Foot Lifter.
With direct drive motor, electric presser foot lifter and stitch length, this machine offers beautiful sewing quality and high productivity.
Technical Specification
| Model | Brother S-7180A-813 |
|---|---|
| Max. Sewing Speed | 5,000 sti/min |
| Max. Back Tacking Speed | 3,200 sti/min |
| Max. Stitch Length | 5mm |
| Thread Trimmer Type | Double action thread trimming mechanism |
| Thread Presser | Standard Equipment |
| Hand Switch | Standard Equipment |
| LED Light | Standard Equipment |
| Electric Presser Foot Lifter | Standard Equipment |
| Height of Presser Foor Lifter | Knee Lifter: 10-15mm Automatic Presser Bar Lifter: 12mm |
| Needle (DBx1 / DPx5) | #11-#18 |
| Height of Feed Dog | 0.9mm |
| Motor | AC Servo Motor |
| Weight | 37KG |
| Power | Single-Phase: 200-240V Max. Power Consumption: 400VA |
More Information
| Part No | BROS7180A813 |
|---|---|
| Weight (KG) | 44.000000 |
| Manufacturer | Brother |
