134 SPI SERV7 SIZE 90 PACK OF 10 NEEDLES SCHMETZ

Part No 134SPISERV7X90
Schmetz 20:05MA17 - 134 SPI SERV 7, 135X5 SPI SERV 7, DPX5 SPI SERV 7 - NM 90 / Size 14 - SPI (Acute round point) Packet of 10 Needles.
£2.95
Only 12 Left In Stock!

Description / 134 SPI SERV7 SIZE 90 PACK OF 10 NEEDLES SCHMETZ

Schmetz 20:05MA17 - 134 SPI SERV 7, 135X5 SPI SERV 7, DPX5 SPI SERV 7 - NM 90 / Size 14 - SPI (Acute round point) Packet of 10 Needles.

SPI (Acute round point)
Needles with a acute round point "SPI" that is very slim, allow accurate piercing of densely woven and coated materials. Additionally, this point shape enables you to get exact seam appearance while avoiding seam puckering.

SCHMETZ SERV 7
Besides fabric damage, skip stitches are a problem that frequently arises when sewing elastic material. To prevent them, SCHMETZ developed the SERV 7 needle. This specially shaped needle is made for almost all needle systems, with all the main point shapes and in all current needle sizes.
The main distinguishing features of the SERV 7 design are the hump scarf that makes a particularly large loop of thread which can be more easily caught by the point of the hook and the blade reinforcement, that ensures the extraordinarily high stability of the needle. To produce the smallest possible stitch holes and optimise fabric displacement, the SERV 7 design thus often allows the use of a needle one size smaller without any reduction in the stability of the needle.
SERV 7 needles have a 15 % reinforcement, and as much as 20 % in some needle sizes. Therefore, the needle is especially stable and far less likely to “bend”. Neither the hook or looper nor other machine parts, e.g. the throat plate, are damaged.


Needle Specification

Customary Needle Designations 134 SPI SERV 7, 135X5 SPI SERV 7, DPX5 SPI SERV 7
CANU 20:05MA17
NM / Size NM: 90 / Size: 14
Point Style SPI (Acute round point)
Special Variant Special blade reinforcement and hump scarf, to avoid skipped stitches and reduce needle breakage
Type of Coating Chrome
Shank-ø 2 mm
Overall Length 38.7 mm
Length to Eye 33.9 mm
Shank Flattening Without shank flattening
Blade Shape Straight
Number of Grooves 1
Stitch Type Lockstitch

More Information

Part No 134SPISERV7X90
Weight (KG) 0.015000
Manufacturer Schmetz
Needle Size NM 90 / Size 14
