134CL SAN1 SIZE 160 GROZ BECKERT DISCONTINUED
Part No
134CLSAN1X160
Groz Beckert - 134 CL SAN 1 - NM 160 / Size 23 - R (Regular Round Point) Packet of 10 Needles.
£4.43
Only 10 Left In Stock!
Description / 134CL SAN1 SIZE 160 GROZ BECKERT DISCONTINUED
Groz Beckert - 134 CL SAN 1 - NM 160 / Size 23 - R (Regular Round Point) Packet of 10 Needles.
R (Regular Round Point)
- Slightly rounded shape of the point
- Suitable for knitted and woven fabrics and microfiber
- Standard point for chainstitch as well as single and multihead embroidery
- Perfectly suited for button sewing
SAN™ 1 for embroidering products made from sturdy materials
The SAN™ 1 version is particularly suitable for embroidering products made of sturdy materials such as baseball caps or leather. The reinforced blade increases the stability of the needle and the special geometries of the scarf and eye improve the pick-up of the loop. In addition, the larger eye simplifies threading and allows the embroidery thread to slide through unhindered.
Needle Specification
| Customary Needle Designations | PFX134 CL SAN 1, 797 CL SAN 1, 135X7 CAP 7, 20:05 |
|---|---|
| Further point designations | STU, STUB, S BALL, SET RT, EH, H SET, NEW RD, R STU, R |
| NM / Size | NM: 160 / Size: 23 |
| Type of Coating | Chromium |
| Special application needle | SAN™ 1 for the embroidery on sturdy products (f. ex. baseball caps) |
| Shank-ø | 2 mm |
| Overall Length | 38.9 mm |
| Length to Eye | 33.9 mm |
| Needle Form Description | Straight needle with single groove and scarf |
| Technical Sewing Application | Double lock stitch |
| Stitch Type Class | 300 |
| Special(s) | Point groove left |
| Recommended For | Fine knitwear, Woven fabrics, Thin leather |
| Examples of Use | Shirts, Blouses, Trousers |
More Information
| Part No | 134CLSAN1X160 |
|---|---|
| Weight (KG) | 0.015000 |
| Manufacturer | Groz Beckert |
| Needle Size | NM 160 / Size 23 |
